Largest Stockholder of Nickel Alloy 800H Pipe Fittings in India, 800HT Incoloy WPNIC10 Pipe Elbow Trader, Competitive Price of Incoloy 800 SR Elbow, Incoloy Alloy 800 Equal Tee, Ready Stock of X10NiCrAlTi32-20 Incoloy® Alloy Buttweld Elbow, ASTM B366 800H Buttweld Fittings Manufacturers in Mumbai, India.

Kalikund Steel & Engg. Co. is the leading manufacturer and supplier of the excellent quality of Incoloy 800/H/HT Buttweld Fittings. These Incoloy 800 fittings are provided to the national and international buyers at different specifications according to their needs and demands. The buyer can easily acquire it at various standards, sizes, wall thicknesses, schedules, and types. We are supplying these Fittings in customized and non-customized forms. These Incoloy 800/H/HT Buttweld Fittings is the chromium, nickel, and iron stabilized alloy that is the part of 800 series alloy family. Also, it is called as nickel 800H alloy. The best thing about this Incoloy Buttweld Fittings is that it is resistant to prolonged exposure to elevated temperature. It has the ability to resist carburization, oxidation, and sulfidation. Also, the added carbon and annealing treatment permits for the higher creep and stress rupture properties. It is also resistant to higher temperature corrosion. The Incoloy Fittings are machined readily using the standard methods. These Incoloy 800 H/ HT Buttweld Fittings also possess the feature of aqueous corrosion at the moderate temperature.

These Kalikund Steel & Engg. Co. are having the many good qualities found in the offered ranges of Incoloy 800/H/HT Buttweld Fittings. Our excellent Fittings has many qualities are like high tensile strength, Rugged construction, Pitting and oxidation resistance, stress corrosion cracking and crevice corrosion resistance, Holds high temperature, Fine surface finishes, Sturdiness, Long-lastingness, Working ability, Fabric ability and many more. We, Kalikund Steel & Engg. Co. has the big manufacturing unit in our organization to manufacture these Incoloy 800/H/HT Buttweld Fittings in the vast quantity to meet the demand of our esteemed clients. In our manufacturing unit, we are also having the modern and latest technologies of production of these Incoloy 800 Fittings. We are testing raw materials before using for

Incoloy 800 Buttweld Pipe Fittings

Incoloy Alloy 800H Buttweld Pipe Bend, Incoloy WPNIC11 Dish Cap, Buy Incoloy UNS N08810 Butt weld Reducer, Incoloy 1.4876 Buttweld Cross Wholesaler, Grade 800 Incoloy Alloy Butt weld Pipe Fittings Dealer, Alloy 800 Two Joint Pipe Fittings, 800H Incoloy® Alloy Buttweld Pipe Fittings Stockist, ASME SB366 800HT Collar Pipe Fittings, ANSI B16.9 800 Incoloy Alloy Buttweld Pipe Cap, NA 15 Incoloy Long Stub End Supplier in Mumbai, India.

We are having the experts and skilled employees for the manufacturing of these Incoloy 800/H/HT Buttweld Fittings, who always works hard to manufacture the best quality of Incoloy Fittings by supervising the whole process strictly. We, Kalikund Steel & Engg. Co. are delivering these Incoloy 800/H/HT Buttweld Fittings to our esteem clients with all beneficial features. We test these Fittings at various stages of production by performing different destructive and non-destructive tests. We are offering Fittings by packing them in proper materials to avoid damages in transport. With the help of our experts and fast shipping modes, we are delivering them on-time.


Largest Inventory
Customer Support
On Time Deliveries
ISO 9001 : 2015 Certified

Incoloy 800/800H/800HT Buttweld Fittings Specification

800/800H/800HT Pipe Fittings Specifications ASTM B366/ ASME SB366
800/800H/800HT Incoloy Alloy Pipe Fittings size 800HT Seamless Butt Weld Fittings : 1/2" - 10"
800 Welded Butt Weld Fittings : 1/2" - 48"
Alloy 800/800H/800HT Pipe Fittings Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Incoloy 800/800H/800HT Buttweld Fittings Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
800/800H/800HT Buttweld Pipe FittingsType DN15-DN1200
ASTM B366 800/800H/800HT Buttweld Fitting Connection Welding
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Grade 800HT Pipe Fitting
Size Range ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 800 Buttweld Fitting
ASTM B366 800/800H/800HT Buttweld Fittings Manufacturing process Push, Press, Forge, Cast, etc.
800/800H/800HT Incoloy Buttweld Pipe Fittings Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
SA 366 800/800H/800HT Pipe Fittings Origin & Mills Japanese, Indian, USA, Korean, European, Ukraine, Russian
Specialized manufacturer of Alloy UNS N08800, N08810, N08811 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend
We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Incoloy 800 Butt weld Pipe Fittings can be supplied in either seamless or welded construction and are covered by specification ASTM B366 and ASME B16.9.

Manufacturing Standards of Incoloy 800/800H/800HT Buttweld Fittings

ASME B16.9 ASTM B366 800 Pipe Fittings Factory-Made Wrought Buttwelding Fittings Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28   Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
Mss SP75   Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers
ANSI B16.9 Incoloy 800/800H/800HT Buttweld Fittings Forms & Availability

Seamless/ Welded 100% Radiography Tested

Products Size
ASTM B366 800/800H/800HT Incoloy Alloy Elbow – Long Radius ASTM B366 800/800H/800HT Incoloy Alloy Stub Ends Sizes 1/2″ – 48″
ASTM B366 800/800H/800HT Incoloy Alloy Elbow – Short Radius ASTM B366 800/800H/800HT Incoloy Cross
ASTM B366 800/800H/800HT Alloy 3D Elbow ASTM B366 800/800H/800HT Incoloy Alloy 5D Elbow
ASTM B366 800/800H/800HT Incoloy Alloy Reducing Elbow ASTM B366 800/800H/800HT Incoloy Alloy Reducing Cross
ASTM B366 800/800H/800HT Alloy 45° Elbow ASTM B366 800/800H/800HT Alloy Tees
ASTM B366 800/800H/800HT Incoloy Alloy Fabricated Tee ASTM B366 800/800H/800HT Alloy End Cap
ASTM B366 800/800H/800HT Alloy Reducer ASTM B366 800/800H/800HT Alloy Coupling
ASTM B366 800/800H/800HT Incoloy Alloy Concentric Reducer ASTM B366 800/800H/800HT Incoloy Alloy Eccentric Reducer
ASTM B366 800/800H/800HT Incoloy Alloy Pipe Nipple ASTM B366 800/800H/800HT Incoloy Alloy Welded Pipe Fittings

Incoloy 800/800H/800HT Pipe Fittings has the following advantages :
  • Good general corrosion resistance and high strength
  • Good sulfide stress corrosion resistance
  • Resistance to chloride pitting and crevice corrosion
  • Higher resistance to chloride stress corrosion cracking
  • Easy to weld and conform
Some of Our Specialities that make us a profitable Business Partber for our clients are :
  • Customer focused approach
  • Superior quality products
  • Timely deliverices
  • Customize Size & Specification
  • Competitive Pricing
Kalikund Steel
Stock Availability of ASME SA 366 Incoloy 800/800H/800HT Pipe Fittings
Preview Products UNS DIN
Incoloy 800/800H/800HT Elbow Incoloy 800/800H/800HT Elbow UNS N08800/N08810/N08811 Elbow 1.4876/1.4958/1.4859 Elbow
Incoloy 800/800H/800HT Tee Incoloy 800/800H/800HT Tee UNS N08800/N08810/N08811 Tee 1.4876/1.4958/1.4859 Tee
Incoloy 800/800H/800HT Cross Incoloy 800/800H/800HT Cross UNS N08800/N08810/N08811 Cross 1.4876/1.4958/1.4859 Cross
Incoloy 800/800H/800HT Reducer Incoloy 800/800H/800HT Reducer UNS N08800/N08810/N08811 Reducer 1.4876/1.4958/1.4859 Reducer
Incoloy 800/800H/800HT Stub End Incoloy 800/800H/800HT Stub End UNS N08800/N08810/N08811 Stub End 1.4876/1.4958/1.4859 Stub End
Equivalent Grades Incoloy 800/800H/800HT Buttweld Pipe Fittings
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T
Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T
Incoloy 800HT 1.4859 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 - X8NiCrAlTi32-21 XH32T
Chemical Composition of Incoloy 800/800H/800HT Buttweld Fittings
Grade C Mn Si S Cu Fe Ni Cr Al Ti
800 0.10 max 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800H 0.05 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800HT 0.06 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60ᴬ 0.15 – 0.60ᴬ
Mechanical Properties of Incoloy B366 800/800H/800HT Butt weld Pipe Fittings
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
800 / 800H / 800HT 7.94 g/cm3 1385 °C (2525 °F) Psi – 75,000 , MPa – 520 Psi – 30,000 , MPa – 205 30 %
Kalikund Steel
ASTM B366 800H Pipe Fitting Classes for Grades

CR : Corrosion resistant grade. S through WU Classes do not apply.

800-S : Seamless

800-W : Welded, Weldable, RT or UT all pipe starting material welds made with filler metal. All fitting manufacturer welds except as excluded in A/SB366 paragraph 5.4.3.
If UT is substituted for RT, all welds must be examined 100% for their length as required by A/SB366 paragraph 5.6

800-WX : RT all welds with or without filler metal.

800-WU : UT all welds with or without filler metal.

grade-grade-class : Insert grades (800-800) and class (S,W,WX, or WU). Applies to fittings meeting all chemical and physical requirements of both grades.


Incoloy 800 Buttweld Pipe Fittings Production Range
Incoloy 800 Butt weld Elbow
Incoloy 800H Butt weld Tee
Incoloy 800HT Butt weld Cross
Incoloy 800 Butt weld Reducer
Incoloy 800H Butt weld Pipe Cap
Incoloy 800HT Butt weld Pipe Bend
Incoloy 800 Butt weld Stub End
Incoloy 800 Butt weld Lateral Tee
Incoloy 800 Butt weld Pipe Nipple
Kalikund Steel
Incoloy 800/800H/800HT Buttweld Fittings Standard
American Steel Pipe Fittings Standard
Standard Code Standard Name
ANSI ASME SA-366 Forged Durimet pipe fittings
ANSI ASME B16.9 Factory-Made wrought steel pipe fittings
ANSI ASME B16.28 Wrought steel butt-welding short radius elbows and returns
ISO 5251 Incoloy butt-welding fittings
MSS SP-43 Wrought Incoloy butt-welding fittings
MSS SP-75 Forging butt-welding fittings
German Steel Pipe Fittings Standard
DIN 2605 Steel butt-welding pipe fittings.elbows and bends
DIN 2615 Steel butt-welding pipe fittings.tees
DIN 2616 Steel butt-welding pipe fittings.reducers
DIN 2617 Steel butt-welding pipe fittings.caps
Japanese Steel Pipe Fittings Standard
JIS B2311 Universal steel butt-welding pipe fittings
JIS B2312 Steel butt-welding pipe fittings
JIS B2313 Steel plate butt-welding pipe fittings
Other Steel Pipe Fittings Standard
EN 1025 3 Butt-welding pipe fittings
Price List of ANSI B16.9 Incoloy 800/800H/800HT Buttweld Pipe Fittings

Prices for Alloy 800 Pipe Fittings Products are very affordable.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. KALIKUND STEEL & ENGG. CO. maintains a stock of all standard items and can export them at the best price ASME SA 366 800H Incoloy Pipe Fittings, Buttweld Elbow, Reducer, Tee, Cross, Stub End, Pipe Bend, Seamless Pipe Fittings, Weldable, Welded Pipe Fittings etc.


Incoloy 800/800H/800HT Butt weld Pipe Fittings Ready Stock in India
Incoloy 800 90° LR Elbow 800H Incoloy Seamless Pipe Fittings
Incoloy 800HT 90° Weldable SR Elbow Alloy UNS N08800 Pipe Reducers
ASME B16.9 Incoloy 800 90° Reducing Elbow 800H Nickel Alloy Welded Pipe Fittings
MSS SP-43 Incoloy 800HT Stub End ASTM B366 800 Incoloy Caps
Incoloy NA 15 Pipe Fittings Supplier B366 800H Two Joint Pipe Fittings
ASTM B366 Incoloy 800HT Reducing Tee ASTM B366 800 Lateral Tee Supplier
Sch 10 Incoloy 800H Concentric Reducer Incoloy® Alloy 800HT Welded Pipe Fittings Dealer
Sch 80 Nickel Alloy 800 Eccentric Reducer B366 Grade 800H Industrial Buttweld Pipe Fittings
ANSI B16.9 Incoloy 800HT Pipe Cap UNS N08810 Incoloy Weldable 3D Elbow
800 Incoloy 180° Buttweld Elbow Alloy 800H Lap Joint Stub Ends Stockists
ASTM B366 Gr 800HT 45° Long Radius Elbow Incoloy 1.4876 Incoloy Alloy Short Radius Elbow Exporter
B366 Grade 800 Pipe Bends ASTM B366 800H Incoloy Pipe Elbow
800HT Incoloy 180° LR Return Bend 800 Incoloy® Alloy Seamless Reducing Tee
800H Nickel Alloy Seamless Fittings Incoloy 800HT 1D Elbow/3D Elbow/5D Elbow
Incoloy 800 Weldable 1.5D Elbow 800H Incoloy Alloy Two Halve Butt weld Fittings
Incoloy 1.4958 Stub End Exporter 1 Inch Incoloy 800HT Buttweld Pipe Fittings
6 Inch Incoloy Alloy 800 Buttweld Pipe Fittings 800H Incoloy Buttweld Reducing Nipple
Incoloy Alloy 800HT Seamless Buttweld Fittings Sch 80 Incoloy 800 Pipe Fittings
ASTM B366 Incoloy 800H Eccentric Reducer ASME B16.9 Incoloy X10NiCrAlTi32-20 10D Elbow
X5NiCrAlTi31-20 Incoloy® Alloy Two Joint Pipe Fittings 800HT Incoloy LR Elbow Supplier
Alloy 800 Wrought Austenitic 45 Degree Elbow ASTM B366 800H Welded Pipe Fittings
X8NiCrAlTi32-21 Incoloy Alloy 90° Seamless Elbow Dealer Incoloy 800HT Pipe Fittings Stockist
Incoloy 800 Pipe Fittings Supplier in Mumbai Alloy 800H Butt weld Pipe Fittings Manufacturer in India
Incoloy 1.4958 Pipe Fittings Dimensions Incoloy NA 15(H) Buttweld Reducing Nipple
Wrought Austenitic Incoloy 800HT Pipe Fittings ASTM B366 800 Eccentric Reducer at Best Price
Alloy X10NiCrAlTi32-20 Equal Cross Supplier Suppliers of 800H Nickel Alloy End Pipe Cap
Kalikund Steel
ASTM B366 800/800H/800HT Incoloy Pipe Fittings Applications and Uses


Exporter of 800/800H/800HT Incoloy Buttweld Fittings in the following cities
Manufacturers, Suppliers of Incoloy 800/800H/800HT Butt weld Pipe Fittings :
Bengaluru Mumbai Chennai Hyderabad Kolkata Pune
New Delhi Ahmedabad Jaipur Surat Salem Gandhinagar
Bhiwandi Tiruppur Sivakasi Jamnagar Thiruvananthapuram Rajahmundry
Bhubaneswar Vijaywada Firozabad Bokaro Steel City Rajkot Bharuch
Panna Raipur Cochin Ludhiana Panipat Durgapur
Peenya Pimpri-Chinchwad Channapatna Kharagpur Nashik Bareilly
Varanasi Haldia Rourkela Bangalore Moradabad Indore
Visakhapatnam Trivandrum Pithampur Dibrugarh Angul Gwalior
Coimbatore Kannur Nagpur Vadodara Rudrapur Noida
Agra Bhagalpur Jamshedpur Bhilai Lucknow kanpur
Thane Bhopal Navi Mumbai Vasai Bikaner Maharashtra
